Clamshell Bucket

Additional tools significantly enhance your demolition robot's efficiency and versatility. Explore our extensive and continually growing range of original Brokk attachments and demolition tools designed to support and advance your business.

General info

See load diagram for each Brokk machine
Rotator with continuous rotation
Requires one extra hydraulic function
Only for material handling, not for demolition.
All weights refer to attachments incl. mounting kit

Brokk’s wide range of clamshell buckets transforms your Brokk robot into the perfect machine for sorting material and debris.

Technical Specifications

	Volume	Opening range	Width	Weight	Made for
C01H-20	10 l/0.4 cu ft	429 mm/16.9 in	207 mm/8.1 in	61 kg/135 lbs	Brokk 70⁺
C02H-25	25 l/0.9 cu ft	725 mm/28.5 in	250 mm/9.8 in	110 kg/243 lbs	Brokk 120D, 130⁺
C03H-35	65 l/2.3 cu ft	880 mm/34.6 in	350 mm/13.8 in	175 kg/386 lbs	Brokk 170⁺
C05H-40	115 l/4.1 cu ft	1090 mm/42.9 in	400 mm/15.7 in	210 kg/463 lbs	Brokk 200⁺
C05HPX-40	115 l/4.1 cu ft	1110 mm/43.7 in	400 mm/15.7 in	325 kg/717 lbs	Brokk 300⁺
C05HPX-60	170 l/6.0 cu ft	1110 mm/43.7 in	600 mm/23.6 in	390 kg/860 lbs	Brokk 500⁺, 520D
C08HPX-80	300 l/10.6 cu ft	1250 mm/49.2 in	800 mm/31.5 in	580 kg/1279 lbs	Brokk 900
